My HP Pavilion f1703 LCD Monitor suffered the same blackout symptoms as other posters in the CNET forum. After powering on, the display would go black after a few seconds. It was not the power supply in my case – I tried another working power supply with the same result.
It was also not a software problem, e.g., XP SP2, power management, screensavers, etc. In my case, it was a hardware problem, as I tried the monitor on a different machine with the same result: power on, brief display, then black. It also exhibited this behavior with no cable connected to the monitor.
I noticed the screen was faintly visible under bright light and realized that the backlight was not working. It seemed unlikely that the fluorescent tube would fail – I have had my Toshiba Portege 7200CT notebook computer on for 5 years, running SETI@Home.
Since the monitor was out of warranty, I decided to try to repair it myself. This is not a step-by-step procedure, but an general overview of how I solved MY problem with this monitor.
After reading the posts, it seemed that there must have been a loose connection on the circuit board that drives the monitor’s backlight. I especially noted gromit588’s post about disassembly and followed the instructions. gromit588’s experience must have shorted some connection closed to fix the problem. I found that it did not help me, so I looked for bad (cold) solder joints on the backlight inverter board.
After a close inspection of the board, the bad solder joint was obvious. The bad solder joint on my board was on one of the coils – the bare pin on the coil was sticking through from the component side with very little solder on the pad on the circuit board. I resoldered it and that fixed the problem. There may be other cold solder joints at different locations on YOUR board. You just have to inspect each joint carefully.
This is a view of the monitor disassembled from the case:
This is the component side of the backlight inverter board:
This is the solder side of the backlight inverter board with the bad joint circled:
Close-up of the backlight inverter board with the repaired cold solder joint circled. Inspect the board for cold solder joints – they will be fairly obvious. It’s possible that the cold solder joints on YOUR board are in different locations on the board from the one circled here: (Jan. 23, 2009: If the cold joints aren’t obvious, I recommend using a 10x magnifier, or just reheat the solder joints on the components that have white glue holding them to the circuit board, see fig. 2)
